Diagnosing and Resolving Vibration Issues in Thermal Separation Units

To keep your operations safe and efficient, it is important to quickly diagnose and correct vibration issues. Vibrations during operation, if left unchecked, can lead to serious damage to critical components such as rotors, bearings, thermal bodies, and mechanical seals.

Recognizing the Problem

When vibration occurs during operation, you need to diagnose immediately. Operators must quickly identify and eliminate the root cause to prevent component damage. If vibrations exceed tolerance, consider shut down until the underlying issue is resolved. Vibrations are generally categorized by their frequency and amplitude, each pointing to different potential causes.

High-Amplitude, Low-Frequency Vibrations

These types of vibrations often indicate problems related to process conditions or installation faults. Common causes include:

  • Backup of Product: Excess accumulation of product in both the feed and discharge zones in the process area can lead to imbalanced operation and significant vibrations.
  • Overconcentration of Product: High product concentration can increase material viscosity, causing resistance and uneven operation.
  • Air Leaks in Discharge System: Leaks can disrupt the flow dynamics, potentially creating two-phase flow, leading to instability.
  • Improper Installation: Incorrect assembly or alignment can introduce structural vulnerabilities.
  • Inadequate Support Structure: Weak or improperly designed support can amplify operational vibrations.
  • Condensate and Non-condensables in Jackets: Undersized or faulty condensate traps may lead to inefficiencies and vibration.

Low-Amplitude, High-Frequency Vibrations

These vibrations are often indicative of wear-and-tear or maintenance-related issues. Possible causes include:

  • Heavy Deposits on Heating Jacket Walls: Accumulation of materials can disrupt heat transfer and cause uneven operation.
    • Common when rotor to wall gap exceeds OEM tolerance.
  • Heavy Deposits on Blades: Similar to the heating jacket, deposits on wiper blades can create operational imbalances.
  • Worn Bearings: Both lower guide or bearings and upper bearings, when worn, can lead to increased vibrations.
  • Loose V-Belts: Improperly tensioned V-belts on the rotor drive motor can destabilize the system.
  • Improper Installation and Misalignment: As with low-frequency vibrations, structural inadequacies remain a significant factor.
Effective diagnosis and resolution
of vibrations maintains system performance

Diagnosis and Corrective Measures

When diagnosing the source of vibration, start with external factors such as product accumulation, air leaks, and structural integrity. If external factors are ruled out, the focus should shift to internal components, particularly the balance of the rotor.

  • Inspection Protocols: Conduct thorough visual and mechanical inspections to identify wear, deposits, and misalignments.
  • Preventive Maintenance: Implement cleaning protocols for shut down procedures and batch change-outs and perform periodic checks on bearings, assemblies and V-belts.
  • Rotor Inspection and Balancing: If external causes are eliminated, LCI can perform rotor inspections, balancing checks, and realignment.

Effective diagnosis and resolution of vibrations maintains system performance and prevents costly downtime. By understanding the common causes and adopting a systematic approach to diagnosis, operators can address vibration issues promptly and efficiently. Regular maintenance and adherence to installation best practices further ensure long-term reliability, safety, and efficiency.
